Application Cases
Field photos from PATTERN residential and commercial energy storage installations across Nigeria, Vietnam and beyond — batteries, hybrid inverters and complete systems delivered and commissioned by our local teams.
Residential · Nigeria
PATTERN hybrid inverter wall-mounted above a 15kWh floor-standing LiFePO4 battery, wired through dedicated breaker boxes — whole-home backup for daily grid outages.
Residential · Nigeria
Hybrid inverter and floor-standing battery commissioned on site with a laptop — parameters set, self-consumption and backup switchover verified before handover.
Residential · Nigeria
Inverter and 15kWh floor-standing battery installed during renovation, with surface-run conduit, AC/DC breakers and a fire safety device mounted alongside.
Residential · Nigeria
A tidy living-area installation — hybrid inverter on a steel bracket, floor-standing battery below on casters, and a combined distribution box at hand height.
Residential · Nigeria
Retrofit into an occupied apartment: inverter and battery fitted into a utility corner, with surge protection and battery cabling dressed to the existing DB.
Residential · Nigeria
Space-saving corner build — inverter on a wall bracket with distribution box and AC disconnect on a shared rail, battery standing below on a raised plinth.
Residential · Nigeria
A certified installer walks the homeowner through the new system — checking inverter readings against the commissioning checklist before sign-off.
Commercial · Nigeria
Four floor-standing LiFePO4 batteries in parallel under test — bypass switches, PV/AC distribution boxes and a DC bus bar labeled and dressed for a commercial site.
Service Center · Nigeria
Our Nigeria service center runs a live test bench of PATTERN inverters and batteries — used for pre-delivery inspection, firmware setup and installer training.
Commercial · Nigeria
Two hybrid inverters and two floor-standing batteries in a dedicated utility room — paralleled for higher output, with labeled breaker boxes and clean cable runs.
Residential · Nigeria
A minimalist finish: wall-mounted battery under the hybrid inverter with conduit-runs hidden, battery monitor display at eye level for daily checks.
Logistics · Nigeria
UN3480 lithium battery export crates delivered to site — the local team unpacking a floor-standing ESS unit for same-day installation.
C&I · Vietnam
Engineers commissioning two floor-standing batteries with a wall-mounted hybrid inverter in a tiled utility room — replacing an aging board of manual changeover switches.
